  3. NoTouch® Cast Aluminum Switch
NoTouch Cast Aluminum Switch featured product model

DETAILS

NoTouch® Cast Aluminum Switch

Helps Stop the Spread of Germs

This cast aluminum motion sensor switch applies NoTouch® technology which helps reduce the spread of germs in any public building. To trigger the button, a person must simply wave their hand in front of the device to exit the building. The infrared (IR) will detect the motion and unlatch the time adjustable door. Each motion sensor switch is constructed of cast aluminum, allowing the device to take tough knocks in stride. The faceplate is slightly oversized for retrofit applications to cover marks from a previous install. Durable and long lasting, the button is easily installed within minutes right on site.

Key Features

DESIGN
DESIGN
  • Touch free button applies NoTouch technology to help eliminate the spread of germs in any public building.
CONSTRUCTION
CONSTRUCTION
  • Faceplate constructed of heavy duty die cast aluminum.
  • Button constructed of polycarbonate.
  • Switch plate and backbox .062" (1.6mm) thick.
INSTALLATION
INSTALLATION
  • Operating temperature 14°F to 158°F (-10°C to 70°C).
  • Operating life:
    • Mechanical relay 1,000,000 cycles
    • IR sensor 100,000 hours
  • Faceplate is slightly oversized to cover old installation marks.
ELECTRONICS
ELECTRONICS
  • NoTouch® active infrared detection.
  • Operating voltage 12VDC - 24VDC, 45mA (max.).
  • Detection range 1.5~6in., 4cm~15cm (±25%).
  • Form "C" dry contact, 0.5A @120VAC, 1A @ 24VDC.
  • Adjustable relay latch 0.5~20 sec.
OPTIONS
OPTIONS
  • Three interchangeable, illuminated LED message lenses included
    • Blue EXIT, green EXIT, white OPEN
  • Available sizes
    • US single gang, backbox available
    • European single gang, backbox available
  • Custom text available.
